| Channel Supported | Dual Channel |
|---|
Expansion Slots
| PCI Express 3.0 x16 | 1 x PCI Express 3.0 x16 Slot (PCIE2: x16 mode)* * Supports NVMe SSD as boot disks |
|---|---|
| PCI Express x1 | 1 x PCI Express 2.0 x1 Slot |
Storage Devices
| SATA 6Gb/s | 4 x SATA3 6.0Gb/s Connectors, support NCQ, AHCI and Hot Plug |
|---|
Onboard Audio
Onboard LAN
| LAN Chipset | Realtek RTL8111H |
|---|---|
| Max LAN Speed | 10/100/1000Mbps |
Rear Panel Ports
Internal I/O Connectors
| Onboard USB | 1 x USB 2.0 Header (Supports 2 USB 2.0 ports) (Supports ESD Protection) 1 x USB 3.1 Gen1 Header (Supports 2 USB 3.1 Gen1 ports) (Supports ESD Protection) |
|---|---|
| Other Connectors | 1 x TPM Header 1 x Chassis Intrusion and Speaker Header 1 x CPU Fan Connector (4-pin)* 1 x Chassis/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)** 1 x Front Panel Audio Connector* The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power. ** The Chassis/Water Pump Fan supports the water cooler fan of maximum 2A (24W) fan power. ** CHA_FAN1/WP can auto detect if 3-pin or 4-pin fan is in use. |
Physical Spec
| Form Factor | Micro ATX |
|---|---|
| Dimensions (W x L) | 7.5″ x 7.4″ |
| Power Pin | 1 x 24-pin ATX Power Connector 1 x 8-pin 12V Power Connector |
Windows Compatibility
| Windows 11 | Supported |
|---|
